  AMWP8-1100 AMWP9.5-1100
Max plattform height 150 kg 125 kg
Max users 1 1
Working height 8,00 m 9,50 m
Plattform height 6,00 m 7,50 m
Length 1,40 m 1,40 m
Width 0,82 m 0,82 m
Height 1,98 m 1,98 m
Plattformsize 0,78 x 0,70 m 0,78 x 0,70 m
Plattform extension 0,55 m 0,55 m
Turning radius 0 0
Drive motor 2 x 12VDC / 0,4 kw 2 x 12VDC / 0,4 kw
Lift motor 24VDC / 2.2 kw 24VDC / 2.2 kw
Speed (compact) 4 km/h 4 km/h
Speed (errected) 1,1 km/h 1,1 km/h
Up / down speed 43 / 35 sec 43 / 35 sec
Batteries 2 x 12 V / 100 Ah 2 x 12 V / 100 Ah
Integrated charger 24 V / 11 A 24 V / 11 A
Slope 25 % 25 %
Tires ø 230×80 mm ø 230×80 mm
Weight 1120 kg +/-5% 1250 kg +/-5%
